Project Meshtastic
Experiments with Meshtastic
Status In progress
Contact bertrik
Last Update 2025-09-01

Intro

The page describes the research done to figure out if Meshtastic can be used to transfer citizen science measurement data.

The proposition of what I want to achieve:

  • a citizen science data sensor sends measurement data into the meshtastic network
  • at some point the data reaches a meshtastic node that is connected to the internet, which forwards it over MQTT
  • a central listener process picks up the data from the internet and processes it further (e.g. forward it to sensor.community)

Stuff to research:

  • how extensive is the network, see meshnet.nl coverage map
  • how reliable is the network:
    • Nodes have a wide range of technical configurations, however the majority of nodes appear to use the following:
      • LongFast channel with encryption key '1' is used at 869.525 MHz
      • Internet-connected nodes in the Netherlands are usually connected over MQTT at mqtt.meshnet.nl
      • a fraction of about 1-in-5 nodes appears to be connected to internet
      • hop limit of 3, this is the default
      • most nodes are in CLIENT mode (this is good)

Other info:

TODO

  • create a particulate matter sensor that sends meshtastic
  • write a backend/plugin for my sensor-data-bridge

Meshcore

Design

Overall design

  • citizen science nodes send data in meshtastic-compatible format, so packets can be routed accross the meshtastic network
  • data is sent from the node typically every 5 minutes
  • data is broadcast inside the network, until it reaches a node with a MQTT backend connection, typically within a maximum of 3 hops.
  • data arriving at the MQTT server is picked up by a backend application, which can then process it further

Protocol design

  • Use the common LongFast channel, with the default key, this makes sure that other nodes understand our message and are able to forward it over MQTT
  • Follow the the MeshPacket structure, wrap our citizen science playload in a protobuf with specific portnr (PRIVATE_APP = 256), with the "OK-to-MQTT" bit enabled.
  • Citizen science payload has its own custom encoding, as usual, so it is basically opaque to meshtastic, just a byte array
  • A 32-bit checksum message authentication code (MAC) allows us to verify that it really is our citizen science data packet after decryption
  • Each packet already has a semi-unique packet id. Combined with the node id, we consider this unique, so we can identify duplicates at the backend

Checksums

The idea is to send the payload 'unencrypted', which means without any additional encryption layer on top of the standard public LongFast meshtastic encryption, but with a MAC (message authentication code) appended to the message.

The MAC allows you to determine that the packet is really yours and not some other random private-data packet from another user. The MAC includes the sender address and unique packet id, so it will be different for different nodes and is resistant to replay attacks.

The MAC is derived as follows:

  • blake2s algorithm over the following fields:
    • passphrase encoded as ascii, without 0-terminator
    • sender address (little-endian)
    • packet id (little-endian)
  • the MAC determined as the last 4 bytes of the resulting blake hash

Backend

  • The backend application listens on a topic on the de-facto central MQTT server for the netherlands, used by most meshtastic nodes, which is mqtt.meshnet.nl
  • Decoding works as follows:
    • Decrypt with the pre-shared-key (this always work but might result in garbage)
    • Find packets with portnum 'private data'
    • Calculate MAC for all known secret passphrases. When finding a packet with matching MAC, it is almost certainly a packet generated by 'us'
    • Match the device address against a list of known devices
    • Check the unique packet id, check that it has increased since the last known packet received
  • If all of the steps above check out, consider it to be a valid packet
  • Check in a local cache if this is a duplicate packet and if so, ignore it
  • process citizen science data payload: there is no such thing as TTN attributes, so any data required for further forwarding need to be kept locally (e.g. login credentials for opensense / sensor.community)

Packet structure

On the LoRa radio level:

[ 16-symbol preamble | lora explicit header | lora payload ]

Within the lora payload:

[ meshtastic 16-byte header | meshtastic private-data protobuf ]

The protobuf is encrypted using key "AQ==" and a nonce derived from data in the 16-byte header.

Within the meshtastic protobuf:

[ portnum (256:private-data) | private-data | ok-to-mqtt flag ]

The portnum indicates 'private data'. The private-data is not encrypted separately. The flag contains the ok-to-mqtt bit.

Within the private-data:

[ citizen-science payload | 4-byte message authentication code ]

With respect to security coding:

  • The payload is *not* encrypted, but it suffixed by a message authentication code (MAC)
  • The MAC is only 32-bit, to keep the length manageable

Protocol

See https://meshtastic.org/docs/overview/mesh-algo/

Quick links:

Software

I wrote python scripts to interact with the MQTT server and arduino code to run on a LoRa capable ESP32 microcontroller.

See https://github.com/bertrik/mesh-backend

Hardware

Nice antenna? https://nl.aliexpress.com/item/1005007301116616.html

MQTT

In the netherlands, data is typically sent to the 'meshnet.nl' MQTT server, for example

 mosquitto_sub -h mqtt.meshnet.nl -u boreft -P meshboreft -t "#" -v

Examples of typical data:

 msh/7460-7463/2/stat/!da5857c0 online
 msh/EU_868/NL/2/e/LongFast/!eb66115c �%]�g(=���gx�� H5��Aw=]�gE��H`���������LongFast␦

Topics with data on MQTT have the following structure:

 msh/REGION/2/e/CHANNELNAME/USERID

Sending messages

Requirements for sending mqtt downlinks:

  • the meshtastic node needs to have a channel named "mqtt" (exactly), see https://github.com/meshtastic/firmware/blob/master/src/mqtt/MQTT.cpp#L354
  • the meshtastic node has JSON be enabled in its MQTT settings
  • -> the meshtastic node listens on topic: "ROOT/2/json/mqtt/+", where ROOT = "msh/gouda" in my case
  • -> the mqtt publisher sends to topic: 'msh/gouda/2/json/mqtt/!da639b54' for example
  • example payload:
    {"from": 3663960916, "type": "sendtext", "payload": "Test"}'

Example data

Examples of data as decoded from MQTT using the meshtastic python service wrapper:

packet {
  from: 2732702784
  to: 4294967295
  decoded {
    portnum: POSITION_APP
    payload: "\r\224\234\024\037\025\303\266\233\002\030\n\270\001 "
  }
  id: 663882246
  rx_time: 1741511999
  rx_snr: -18
  hop_limit: 2
  rx_rssi: -128
  hop_start: 3
}
channel_id: "LongFast"
gateway_id: "!da544e50"

Packet with encrypted data:

packet {
  from: 1128181476
  to: 4294967295
  channel: 8
  encrypted: "\007\355{o\340e\352\221\204\3112\365h\304[0\321&\351^{]\264\334\373\320\313>\213\2635\023\345'"
  id: 4272151039
  rx_time: 1741512321
  rx_snr: 5.75
  hop_limit: 4
  rx_rssi: -83
  hop_start: 5
}
channel_id: "LongFast"
gateway_id: "!da5c87d4"
